| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | WA2237 | CLAMP | 2 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 10 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 8 | ||||
| ? | WB3093 | CLAMP, CUSHIONED - 1" | 20 | ||||
| ? | EL0128 | HOSE, HEATER (RETURN) | 1 | ||||
| ? | EL0129 | HOSE, HEATER (SUPPLY) | 1 | ||||
| ? | HC0908 | CLAMP, WORM DRIVE | 4 | ||||
| ? | VN6280 | VALVE, SHUTOFF | 2 | ||||
| ? | SD5209 | BUSHING, PIPE - 3/4" X 5/8" | 2 | ||||
| ? | WB1192 | ADAPTER | 1 | ||||
| ? | WB1063 | ADAPTER, METRIC - 90 DEG | 1 | ||||
| ? | WB1141 | ADAPTER, PIPE TO JIC | 1 | ||||
| ? | WB3097 | CLAMP, CUSHIONED - 1/2" | 1 | ||||
| ? | VD6174 | CLAMP, U-BOLT | 2 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 8 | ||||
| ? | MM0050 | CAPSCREW - M10 X 1.50 X 35 | 1 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 1 |
