| Наименование | Страница | Код страницы |
|---|---|---|
| STEERING COLUMN ASSEMBLY XB8878 | 230 | 41730 |
| RETARDER LEVER ASSEMBLY 58F-06-03940 | 232 | 62903 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58F-06-03940 | RETARDER LEVER ASSEMBLY (SEE INDEX) | 1 | 62903 | |||
| ? | 58F-40-00180 | STEERING COLUMN ASSEMBLY | 1 | ||||
| ? | XB8878 | • COLUMN, STEERING (1) (SEE INDEX) | 1 | 41730 | |||
| ? | 58F-54-00020 | • MULTI-FUNCTION SWITCH ASSEMBLY | 1 | ||||
| ? | 08021-00400 | • CONNECTOR | 1 | ||||
| ? | WB3105 | • FLAT WASHER - M7 | 2 | ||||
| ? | WB3104 | • FLAT WASHER - M5 | 2 | ||||
| ? | WB3103 | • LOCKWASHER - M5 | 2 | ||||
| ? | 58F-09-00000 | • CAPSCREW - M5 X 0.8 X 25 | 2 | ||||
| ? | MM0373 | • NUT - M5 X 0.8 | 2 | ||||
| ? | SD4245 | LOCKWASHER, EXTERNAL TOOTH - #10 | 4 | ||||
| ? | HD6007 | MACHINE SCREW - #10 - 24NC X 3/4" | 4 | ||||
| ? | EK4275 | ANGLE, FORMED | 1 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | 58F-06-03920 | HARNESS, WIRING - RETARDER LEVER | 1 | ||||
| ? | NOTE: (1) NOT SERVICED AS AN ASSEMBLY. | ||||||
| ? | • ORDER INDIVIDUAL COMPONENT PARTS. |
