Каталог Komatsu

k-part

Номер на схеме	Каталожный номер	Название	Количество
?	58B-22-00820	HOUSING, AXLE	1
?	TX8110	SLEEVE (2)	2
?	58B-50-00130	CAPSCREW - 1 3/8" - 6NC X 4"	28
?	EK5634	FLAT WASHER - 1 3/8"	28
?	58B-22-00530	PIVOT EYE ASSEMBLY (3)	1
?	58B-22-00560	• EYE, PIVOT	1
?	58B-22-00550	• BEARING, SPHERICAL (1)	1
?	58B-22-00540	CARRIER, BEARING
?	VN9953	LOCKNUT - 7/8" - 9NC (1)	14
?	58B-22-00520	RETAINER, BEARING (1)	2
?	EH7811	PIN, PANHARD ROD (2)	2
?	XB0690	PIN, DRIVE PIVOT (1)	1
?	VN9952	LOCKNUT - 5/8" - 11NC (2)	2
?	WB3026	CAPSCREW - 7/8" - 9NC X 6 3/4" (1)	14
?	EK1746	RETAINER, PIN (1)	1
?	WB1059	CAPSCREW, 12 PT - 1 1/4" - 7NC X 4 1/2" (1)	5
?	WA0361	FLAT WASHER, HARDENED - 5/8" (2)	2
?	VN9087	CAPSCREW - 5/8" - 11NC X 2 1/2" (1)	3
?	C1541	LOCKWASHER - 5/8" (1)	3
?	EM8109	SHOULDER BOLT - 5/8" - 11NC X 7.16" (FRAME END) (2)	1
?	EM8121	SHOULDER BOLT - 5/8" - 11NC X 7.01" (AXLE END) (2)	1
?	58F-50-00130	SPACER (2)	4
?	EH7812	ANTI-SWAY BAR W/BEARINGS	1
?	EH7813	• BAR, ANTI-SWAY	1
?	VN9351	• RING, RETAINING (2)	4
?	PB9622	• BEARING, SPHERICAL (2)	2
?	D1423	PLUG, PIPE	2
?	58B-22-00510	SPACER	2
?	58B-MP-AK160	NOTE: (1) INCLUDED IN 58B-MP-AK160 NOSE CONE PIN KIT.
?	58B-MP-AK150	(2) INCLUDED IN 58B-MP-AK150 ANTI-SWAY BAR KIT.
?		(3) NOT SERVICED AS AN ASSEMBLY. ORDER
?		INDIVIDUAL COMPONENT PARTS.
