Каталог Komatsu

k-part

Номер на схеме	Каталожный номер	Название	Количество
?	EH9858	BRACKET	2
?	MM0178	NUT - M10 X 1.50	14
?	MM0471	LOCKWASHER - M10	23
?	58B-03-01270	TUBE	1
?	WA5686	CLAMP	2
?	WB3094	CLAMP, CUSHIONED - 1 3/4"	10
?	58F-94-00020	CLAMP, T-BOLT	4
?	EH7753	HOSE	6
?	WB1047	CLAMP, T-BOLT	24
?	WB1088	CLAMP, T-BOLT	4
?	58B-03-01140	TUBE	2
?	TG5720	CAPSCREW - 3/8" - 16NC X 1"	1
?	58B-03-01280	GASKET	1
?	58B-03-00980	HOSE	1
?	58B-03-00990	HOSE	1
?	58B-80-00850	PLATE	1
?	58B-80-00860	PLATE, BENT	1
?	58E-03-01190	ADAPTER, HOSE	1
?	58E-03-01200	VALVE, BALL	1
?	ED8256	TUBE	1
?	EJ5611	TUBE	1
?	KC1255	CLAMP	2
?	MM0470	LOCKWASHER - M8	2
?	MM0594	CAPSCREW - M8 X 1.25 X 25	2
?	MM0712	FLAT WASHER, HARDENED - M8	2
?	PC0818	FITTING, ADAPTER	2
?	PC1780	ADAPTER	1
?	VF5371	CAPSCREW - 5/8" - 11NC X 6 1/2"	4
?	WA4729	FLAT WASHER, HARDENED - 5/8"	4
?	VC1390	LOCKWASHER - 5/8"	4
?	TV1749	NUT - 5/8" - 11NC	4
?	VY8331	CLAMP, VINYL - 1/4"	1
?	WA2237	CLAMP	2
?	WB1196	CLAMP, HYDRA ZORB	2
