Номер на схеме	Каталожный номер	Название	Количество
?	08193-21012	CLIP	2
?	58B-02-02440	BRACKET	1
?	58B-02-02460	BRACKET	1
?	58B-02-02480	BRACKET	1
?	58B-02-03180	COVER ASSEMBLY, TOP	1
?	58B-02-03231	COVER ASSEMBLY, BOTTOM	1
?	58B-02-03260	COVER ASSEMBLY, DOOR	1
?	58B-02-03720	HOSE, DEF SUPPLY	1
?	58B-02-03730	HOSE, DEF SUPPLY	1
?	58B-02-03740	HOSE, DEF SUPPLY	1
?	58B-02-03750	HOSE, DEF SUPPLY	1
?	58B-02-03760	HOSE, DEF RETURN	1
?	58B-02-03770	HOSE, DEF RETURN	1
?	58B-02-03780	HOSE, DEF RETURN	1
?	58B-02-03790	HOSE, DEF RETURN	1
?	WB3856	CLAMP, CUSHIONED - 1 1/8"	2
?	58B-06-20020	BRACKET	6
?	58B-09-00400	LOCKNUT - M10 X 1.50	4
?	58D-54-10410	WASHER - 1/2"	4
?	58D-54-10530	BUSHING, SHOULDER - M12	4
?	58F-09-00410	LOCKNUT - M12 X 1.75	2
?	58F-09-00460	CAPSCREW - M16 X 2.00 X 45	2
?	EK7573	SCREW, CAPTIVE	7
?	EK7907	RETAINER	7
?	EM1398	SPACER	6
?	EM4587	ROD, THREADED	12
?	EM8447	PLATE, BENT	4
?	MM0178	NUT - M10 X 1.50	47
?	MM0461	FLAT WASHER - M10	64
?	MM0462	FLAT WASHER - M12	8
?	MM0464	FLAT WASHER - M16	2
?	MM0471	LOCKWASHER - M10	60
?	MM0472	LOCKWASHER - M12	2
?	MM0474	LOCKWASHER - M16	2
?	MM0605	CAPSCREW - M10 X 1.50 X 25	9
?	MM0608	CAPSCREW - M10 X 1.50 X 40	4
?	MM0617	CAPSCREW - M12 X 1.75 X 25	2
?	MM0619	CAPSCREW - M12 X 1.75 X 35	2
?	MM0620	CAPSCREW - M12 X 1.75 X 40	2
?	WB3093	CLAMP, CUSHIONED - 1"	131
