| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PC2818 | SWITCH, PROXIMITY | 2 | ||||
| ? | WA4770 | MACHINE SCREW - #10 - 24NC X 2" | 4 | ||||
| ? | VC5344 | FLAT WASHER - #10 | 4 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 4 | ||||
| ? | 58F-54-10541 | BRACKET, MOUNTING | 1 | ||||
| ? | XB3033 | BRACKET | 1 | ||||
| ? | TG5720 | CAPSCREW - 3/8" - 16NC X 1" | 2 | ||||
| ? | TV0177 | FLAT WASHER - 5/16" | 4 | ||||
| ? | SC4174 | LOCKWASHER - 5/16" | 4 | ||||
| ? | MM0604 | CAPSCREW - M10 X 1.50 X 20 | 1 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 1 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 1 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 2 | ||||
| ? | WB3097 | CLAMP, CUSHIONED - 1/2" | 2 | ||||
| ? | WB1300 | CLAMP, CUSHIONED - 5/8" | 1 | ||||
| ? | 08193-21012 | CLIP | 1 | ||||
| ? | MM0606 | CAPSCREW - M10 X 1.50 X 30 | 2 |
