| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VN9210 | CAPSCREW - 5/8" - 11NC X 7 1/2" | 4 | ||||
| ? | WA0361 | FLAT WASHER, HARDENED - 5/8" | 4 | ||||
| ? | C1541 | LOCKWASHER - 5/8" | 20 | ||||
| ? | C1525 | NUT - 5/8" - 11NC | 4 | ||||
| ? | TR4090 | CAPSCREW - 7/16" - 14NC X 1 1/2" | 8 | ||||
| ? | TD0795 | LOCKWASHER - 7/16" | 8 | ||||
| ? | TF3237 | CLAMP, SPLIT FLANGE - 1 1/4" | 4 | ||||
| ? | VG9096 | O-RING | 2 | ||||
| ? | HA7896 | HOSE | 1 | ||||
| ? | WA4713 | CLAMP, HYDRA ZORB - 2 1/4" | 4 | ||||
| ? | VC4571 | FITTING, ELBOW - 90 DEG | 2 | ||||
| ? | TF3238 | FITTING, STRAIGHT | 1 | ||||
| ? | C1629 | CAPSCREW - 5/8" - 11NC X 1 3/4" | 4 | ||||
| ? | WA4711 | CLAMP, HYDRA ZORB - 1 3/4" | 2 | ||||
| ? | HA7897 | HOSE | 1 | ||||
| ? | HA7895 | HOSE | 1 | ||||
| ? | 58F-09-00320 | CAPSCREW - 1/2" - 13NC X 2 3/4" | 8 | ||||
| ? | PB6770 | COUPLING, MALE QUICK DISCONNECT | 4 | ||||
| ? | TF8090 | CLAMP, SPLIT FLANGE - 1 1/2" | 2 | ||||
| ? | VG9095 | O-RING | 1 | ||||
| ? | EJ7406 | FLANGE, ADAPTER | 1 | ||||
| ? | TV1918 | CAPSCREW - 1/2" - 13NC X 1 3/4" | 16 | ||||
| ? | TR5445 | LOCKWASHER - 1/2" | 24 | ||||
| ? | VH6718 | CLAMP, SPLIT FLANGE - 2 1/2" | 8 | ||||
| ? | WA0232 | O-RING | 4 | ||||
| ? | PC0678 | MANIFOLD, BRAKE COOLING & HOIST RETURN | 1 | ||||
| ? | VL9963 | CLAMP, SPLIT FLANGE - 3" | 6 | ||||
| ? | WA0237 | O-RING | 3 |
