Каталог Komatsu

k-part

Номер на схеме	Каталожный номер	Название	Количество
?	VE9591	SPRING	2
?	VE9586	SEAL (1)	1
?	VE9581	RING, PISTON (1)	1
?	58E-98-00470	SLEEVE	1
?	58E-98-00040	RING, BACKUP (1)	2
?	58E-98-00020	O-RING (1)	1
?	58E-98-00010	O-RING (1)	1
?	VE9579	PIN	1
?	58E-98-00030	RING, BACKUP (1)	1
?	VE9553	BARREL, CYLINDER	1
?	VE9577	PISTON	1
?	VE9555	BALL (3)	1
?	VE9554	PISTON SHOE ASSEMBLY	9
?	VE9574	RING, RETAINING	4
?	VE9575	WASHER	2
?	VE9573	PIN	2
?	VE7572	LINK	1
?	VE9584	PIN	1
?	VE9564	PIN, DOWEL	2
?	VE9559	SADDLE	1
?	VE9539	O-RING	1
?	VE9533	ROLLPIN	1
?	BF2617	ROLLPIN (2)	4
?	BF2616	BEARING (2)	2
?	BF3176	SWASH BLOCK W/PIN	1
?	VE9531	BEARING, CYLINDER	1
?	VE9557	RETAINER (3)	1
?	VE9556	SPRING	9
?	58E-98-00000	NOTE: (1) INCLUDED IN 58E-98-00000 PUMP SEAL KIT.
?	BF2613	(2) INCLUDED IN BF2613 BEARING KIT.
?		(3) NOT SERVICED SEPARATELY.
