Номер на схеме	Каталожный номер	Название	Количество
?	58B-06-03851	PLATE	1
?	XC2504	BRACKET, LIGHT	5
?	58E-06-05680	BRACKET, LIGHT	1
?	58E-06-18630	PLATE	2
?	58E-65-00083	LABEL, VEC-89	1
?	58E-65-00092	LABEL, VEC-90	1
?	58E-65-00102	LABEL, VEC-91	1
?	EC7458	NAME PLATE - DL2	1
?	EC7459	NAME PLATE - DL3	1
?	EC7460	NAME PLATE - DL4	1
?	EC7462	NAME PLATE - DL1	1
?	MM0459	FLAT WASHER - M6	30
?	MM0469	LOCKWASHER - M6	16
?	MM0471	LOCKWASHER - M10	37
?	MM0581	CAPSCREW - M6 X 1.00 X 16	12
?	58E-06-02030	PLATE, FLOOR	1
?	MM0582	CAPSCREW - M6 X 1.00 X 20	12
?	MM0605	CAPSCREW - M10 X 1.50 X 25	37
?	MM0461	FLAT WASHER - M10	37
?	PB3324	BOOT, SWITCH	1
?	PC3010	LIGHT, DOME	6
?	SR8325	SWITCH, TOGGLE	1
?	WB2200	NAME PLATE - DLS	1
?	PC3258	MACHINE SCREW - #10 - 24NC X 1"	16
?	58E-65-00211	LABEL, VEC-92	1
?	58B-06-03871	TAG, TERMINAL BOARD	1
?	MM0610	CAPSCREW - M10 X 1.50 X 50	5
?	EC7461	NAME PLATE - DL6	1
?	EC7457	NAME PLATE - DL5	1
?	SM2355	LOCKNUT - #10 - 24NC	12
?	58E-06-10640	GASKET	1
?	MM0607	CAPSCREW - M10 X 1.50 X 35	4
?	SP8417	FLAT WASHER - 1/4"	12
