| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58D-98-00040 | VALVE, PRESSURE REDUCING | 1 | ||||
| ? | XA2018 | MANIFOLD | 1 | ||||
| ? | 58F-98-40600 | CARTRIDGE, SOLENOID VALVE (2) | 1 | ||||
| ? | 58F-98-40720 | COIL, SOLENOID | 1 | ||||
| ? | BF5492 | SCREW, SOCKET HEAD | 4 | ||||
| ? | 58F-98-40290 | PLUG, PIPE | 1 | ||||
| ? | PC1769 | VALVE, FLOW CONTROL | 1 | ||||
| ? | BF5509 | SEAL KIT | 1 | ||||
| ? | BF5510 | FITTING, ORIFICE | 1 | ||||
| ? | O-RING (1) | 2 | |||||
| ? | 58F-98-40700 | MOTOR, HYDRAULIC | 1 | ||||
| ? | 58F-98-40500 | LOCKWASHER | 4 | ||||
| ? | 58F-98-40660 | SCREW, SOCKET HEAD | 4 | ||||
| ? | 58F-98-40670 | CABLE, SOLENOID | 1 | ||||
| ? | 58F-98-40740 | NOTE: (1) NOT SERVICED SEPARATELY. INCLUDED IN | |||||
| ? | 58F-98-40740 SEAL KIT. | ||||||
| ? | (2) SOLENOID NOT SERVICED SEPARATELY. |
