| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-40-00050 | TUBE, TIE ROD | 1 | ||||
| ? | 58E-40-00100 | END, ROD - RH | 1 | ||||
| ? | 58E-40-00110 | END, ROD - LH | 1 | ||||
| ? | C1602 | CAPSCREW - 3/8" - 16NC X 1" | 8 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 8 | ||||
| ? | EK3382 | RETAINER, ANTI-ROTATION (1) | 2 | ||||
| ? | PC1682 | BEARING, SPHERICAL (1) | 2 | ||||
| ? | VN9202 | CAPSCREW - 1" - 8NC X 7" | 8 | ||||
| ? | WA0364 | FLAT WASHER, HARDENED - 1" | 16 | ||||
| ? | VH8186 | LOCKNUT - 1" - 8NC | 8 | ||||
| ? | 58F-40-00050 | CLAMP, ROD END | 4 | ||||
| ? | 58E-MP-AK020 | NOTE: (1) INCLUDED IN 58E-MP-AK020 STEERING CYLINDER | |||||
| ? | AND TIE ROD PIN KIT. |
