| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-54-13703 | PLATFORM, LH | 1 | ||||
| ? | XC3533 | PLATE, COVER | 1 | ||||
| ? | MM0606 | CAPSCREW - M10 X 1.50 X 30 | 4 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 12 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 12 | ||||
| ? | 58B-54-01810 | PLATE, COVER | 1 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 9 | ||||
| ? | 58F-80-05040 | COVER, SWITCH | 1 | ||||
| ? | 58F-80-05540 | PLATE | 1 | ||||
| ? | MM0581 | CAPSCREW - M6 X 1.00 X 16 | 3 | ||||
| ? | MM0711 | FLAT WASHER, HARDENED - M6 | 3 | ||||
| ? | 58B-54-04840 | BUMPER | 2 | ||||
| ? | 58B-09-00200 | CAPSCREW, SOCKET HEAD - M6 X 1.00 X 25 | 4 | ||||
| ? | 58E-54-18570 | MOUNT, LADDER | 1 | ||||
| ? | 58E-09-10110 | • BUSHING | 2 | ||||
| ? | TD1230 | • RING, RETAINER | 4 | ||||
| ? | 58E-09-10120 | PIN | 2 | ||||
| ? | SL8698 | RING, RETAINER | 4 | ||||
| ? | 07020-00001 | FITTING, GREASE | 2 | ||||
| ? | XB5184 | SEAT | 2 | ||||
| ? | 58E-54-18950 | SPACER | 4 | ||||
| ? | XC3532 | PLATE, HEADLIGHT MOUNTING | 1 | ||||
| ? | WB3524 | SCREW, HEX HEAD - #12 - 14NC X 3/4" | 4 | ||||
| ? | 58E-06-13190 | BUTTON, PUSH-PULL | 1 | ||||
| ? | VP4693 | GROMMET | 1 | ||||
| ? | MM0610 | CAPSCREW - M10 X 1.50 X 50 | 1 | ||||
| ? | EM1398 | SPACER | 1 | ||||
| ? | 58B-06-20020 | BRACKET | 1 | ||||
| ? | MM0604 | CAPSCREW - M10 X 1.50 X 20 | 2 | ||||
| ? | MM0459 | FLAT WASHER - M6 | 4 |
