| Наименование | Страница | Код страницы |
|---|---|---|
| PLATFORM ASSEMBLY 1/2 58E-54-13713 | 570 | 68975 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-54-13713 | PLATFORM, LH - RETRACTABLE LADDER (SEE INDEX) | 1 | 68975 | |||
| ? | XC2856 | HANDRAIL | 1 | ||||
| ? | 58E-54-13800 | HANDRAIL | 1 | ||||
| ? | 58B-54-04750 | HANDRAIL, HYDRAULIC LADDER | 2 | ||||
| ? | 58D-54-10302 | LADDER, HYDRAULIC | 1 | ||||
| ? | XC3293 | PLATE, MOUNTING | 2 | ||||
| ? | VH3402 | CAPSCREW - 5/8" - 11NC X 1 3/4" | 4 | ||||
| ? | WA0361 | FLAT WASHER, HARDENED - 5/8" | 4 | ||||
| ? | MM0619 | CAPSCREW - M12 X 1.75 X 35 | 18 | ||||
| ? | MM0472 | LOCKWASHER - M12 | 28 | ||||
| ? | MM0714 | FLAT WASHER, HARDENED - M12 | 38 | ||||
| ? | MM0179 | NUT - M12 X 1.75 | 2 | ||||
| ? | MM0620 | CAPSCREW - M12 X 1.75 X 40 | 10 | ||||
| ? | MM0618 | CAPSCREW - M12 X 1.75 X 30 | 12 | ||||
| ? | MM0462 | FLAT WASHER - M12 | 4 | ||||
| ? | WB1303 | CLAMP, CUSHIONED - 3/4" | 2 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 2 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 2 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 2 | ||||
| ? | XC3533 | PLATE, COVER | 1 |
