| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58D-98-01460 | GROMMET, RUBBER | 1 | ||||
| ? | 58D-98-01771 | INVERTER, IGBT POWER | 1 | ||||
| ? | VE4902 | NUT - 1/4" - 20NC | 1 | ||||
| ? | VE7202 | WASHER, NARROW - 1/4" | 1 | ||||
| ? | XA5003 | LOCKWASHER - 1/4" | 1 | ||||
| ? | 58D-98-00630 | RESISTOR ASSEMBLY | 1 | ||||
| ? | VE4601 | LOCKWASHER - #10 | 6 | ||||
| ? | VE4602 | NUT - #10 - 32NF | 7 | ||||
| ? | VE4655 | FLAT WASHER - #10 | 7 | ||||
| ? | GE0756 | LINK SENSOR, AC-DC | 2 | ||||
| ? | PB5230 | RESISTOR, THYRITE | 1 | ||||
| ? | VE4696 | LOCKWASHER - 5/16" | 1 | ||||
| ? | VE5013 | NUT - 5/16" - 18NC | 1 | ||||
| ? | VE4343 | FLAT WASHER - 5/16" | 1 | ||||
| ? | GE1379 | PLUG | 2 | ||||
| ? | 58F-43-01910 | BUS BAR | 1 | ||||
| ? | VE4699 | LOCKWASHER - 1/2" | 11 | ||||
| ? | VE4698 | NUT - 1/2" - 13NC | 11 | ||||
| ? | VE4519 | FLAT WASHER - 1/2" | 10 | ||||
| ? | PB3348 | INSULATOR | 11 | ||||
| ? | GE0579 | STUD | 10 | ||||
| ? | 58F-43-01340 | GROMMET | 1 | ||||
| ? | 58F-43-01240 | GROMMET, RUBBER | 1 | ||||
| ? | XA4876 | CAPACITOR, IGBT INVERTER | 2 | ||||
| ? | VE4518 | CAPSCREW - 1/2" - 13NC X 1 1/2" | 1 | ||||
| ? | XA5273 | SPACER | 1 | ||||
| ? | 58F-43-01020 | BUS BAR | 1 | ||||
| ? | GE0590 | STUD - 1/4" - 20 NC X 3 3/4" | 1 | ||||
| ? | 58D-98-00570 | SENSOR, AC-DC | 3 | ||||
| ? | 58F-43-01330 | PANEL | 3 | ||||
| ? | 58F-43-01730 | STUD | 3 | ||||
| ? | 58F-43-01120 | BUS BAR | 6 | ||||
| ? | 58D-98-00680 | BUS BAR | 1 | ||||
| ? | 58F-43-01350 | BUS BAR | 1 | ||||
| ? | 58F-43-01410 | SENSOR, THERMISTOR | 1 | ||||
| ? | XA3593 | SUPPORT | 1 | ||||
| ? | 58B-43-01200 | RESISTOR BOARD | 2 | ||||
| ? | GE1388 | STUD - #10 - 32NC X 1 3/8" | 1 | ||||
| ? | VE4687 | LOCKWASHER - 3/8" | 1 | ||||
| ? | VE4700 | NUT - 3/8" - 16NC | 1 | ||||
| ? | VE4515 | FLAT WASHER - 3/8" | 1 |
