| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-22-00280 | PINION & GEAR ASSEMBLY | 3 | ||||
| ? | VE4513 | RING | 3 | ||||
| ? | VE4232 | CAP, BEARING | 3 | ||||
| ? | VE8879 | CAPSCREW - 1/2" - 13NC X 2" | 18 | ||||
| ? | VE5185 | FLAT WASHER - 1/2" | 51 | ||||
| ? | BF3896 | WIRE | |||||
| ? | XA4271 | BEARING, ROLLER | 3 | ||||
| ? | 58E-22-00380 | SLEEVE | 3 | ||||
| ? | VE8234 | COLLAR | 3 | ||||
| ? | VE8233 | CAP, BEARING | 3 | ||||
| ? | 58E-22-00370 | BEARING, ROLLER | 1 | ||||
| ? | VE4496 | NUT | 3 | ||||
| ? | VE4497 | LOCKWASHER | 3 | ||||
| ? | 58E-22-00640 | SHAFT & RING GEAR ASSEMBLY | 1 | ||||
| ? | 58E-22-00440 | SEAL, HOUSING (1) | 1 | ||||
| ? | BF3900 | CAPSCREW - 1/2" - 13NC X 1 1/4" | 24 | ||||
| ? | 58E-22-00590 | COUPLING | 2 | ||||
| ? | VE4548 | RING, DRIVE | 1 | ||||
| ? | BF3863 | CAPSCREW - 1/2" - 13NC X 4" | 1 | ||||
| ? | XA2866 | FRAME, HEAD | 1 | ||||
| ? | VE1273 | RING, SEAL (1) | 1 | ||||
| ? | VE3035 | CEMENT - 1 QUART | |||||
| ? | VE4518 | CAPSCREW - 1/2" - 13NC X 1 1/2" | 8 | ||||
| ? | VE0756 | RING (1) | 1 | ||||
| ? | 58D-98-00300 | SEAL, OIL (1) | 2 | ||||
| ? | VE0662 | BAND, WEAR (1) | 2 | ||||
| ? | 58E-22-00580 | PACKING, FELT (1) | 1 | ||||
| ? | VE4236 | SEAL (1) | 1 | ||||
| ? | VE4235 | BAND, WEAR (1) | 1 | ||||
| ? | VS8408 | PIN | 1 | ||||
| ? | VS8411 | PLUG, MAGNETIC | 2 | ||||
| ? | VE4536 | COLLAR | 1 | ||||
| ? | BF2112 | CAP, BEARING | 1 | ||||
| ? | VJ9656 | ADHESIVE, RTV | |||||
| ? | XA2867 | BEARING, ROLLER | 1 | ||||
| ? | XA4276 | HOUSING, BEARING | 1 | ||||
| ? | VE7207 | COLLAR | 1 | ||||
| ? | VE7212 | SEAL, V-RING (1) | 1 | ||||
| ? | BF1660 | SEAL, LIP (1) | 1 | ||||
| ? | VE4737 | CLAMP | 4 | ||||
| ? | 58D-WM-AK010 | NOTE: (1) INCLUDED IN 58D-WM-AK010 WHEEL MOTOR | |||||
| ? | OVERHAUL KIT. |
