| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | MM0461 | FLAT WASHER - M10 | 20 | ||||
| ? | MM0606 | CAPSCREW - M10 X 1.50 X 30 | 8 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 16 | ||||
| ? | WA4830 | T-BOLT CLAMP | 8 | ||||
| ? | 58E-02-00300 | BRACKET | 1 | ||||
| ? | 58E-02-10300 | BRACKET | 1 | ||||
| ? | EM8967 | STRAP | 2 | ||||
| ? | C1547 | FLAT WASHER - 3/8" | 4 | ||||
| ? | MM0608 | CAPSCREW - M10 X 1.50 X 40 | 4 | ||||
| ? | 58E-02-10400 | BRACKET | 1 | ||||
| ? | MM0607 | CAPSCREW - M10 X 1.50 X 35 | 8 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 4 | ||||
| ? | 58E-02-10600 | BRACKET | 1 | ||||
| ? | 58E-02-10630 | PLATE, BENT | 1 | ||||
| ? | 58E-54-16900 | DUCT | 1 | ||||
| ? | 58E-03-10110 | DUCT, FLEX HOSE | 1 | ||||
| ? | 58E-03-10130 | DUCT ASSEMBLY, RIGID | 1 | ||||
| ? | 58E-03-10120 | DUCT, FLEX HOSE | 1 |
