| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-60-01981 | HOSE | 1 | ||||
| ? | 58B-04-10230 | HOSE | 1 | ||||
| ? | 58E-60-01991 | HOSE | 1 | ||||
| ? | 58F-94-00010 | CLAMP, T-BOLT | 1 | ||||
| ? | 58E-60-02130 | HOSE | 1 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 2 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 18 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 18 | ||||
| ? | WB3096 | CLAMP, CUSHIONED - 1 1/4" | 1 | ||||
| ? | TG5722 | CAPSCREW - 7/16" - 14NC X 1" | 6 | ||||
| ? | TD0795 | LOCKWASHER - 7/16" | 6 | ||||
| ? | EL3892 | SPACER | 1 | ||||
| ? | WB3855 | CLAMP, CUSHIONED - 13/16" | 9 | ||||
| ? | WB1300 | CLAMP, CUSHIONED - 5/8" | 5 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 16 | ||||
| ? | 58E-80-03720 | PLATFORM, GREASE PUMP | 1 | ||||
| ? | WB3855 | CLAMP, CUSHIONED - 13/16" | 1 | ||||
| ? | WB3093 | CLAMP, CUSHIONED - 1" | 1 | ||||
| ? | WA3098 | FITTING, ELBOW - 90 DEG | 1 | ||||
| ? | WA2567 | FITTING, CAPNUT | 1 | ||||
| ? | EM8447 | PLATE, BENT | 1 | ||||
| ? | WB0268 | FITTING, ELBOW - 90 DEG | 2 | ||||
| ? | MM0610 | CAPSCREW - M10 X 1.50 X 50 | 1 | ||||
| ? | 58E-80-04250 | BRACKET | 1 | ||||
| ? | 58E-80-03750 | BRACKET | 1 | ||||
| ? | 58B-60-40070 | ORIFICE, DISC | 1 | ||||
| ? | SG3146 | GROMMET | 1 |
