| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-54-27590 | PLATFORM, DOOR | 1 | ||||
| ? | 58F-09-00040 | • SCREW, FLANGE BUTTON HEAD - M10 X 1.50 X 20 | 12 | ||||
| ? | 58E-54-16892 | DECK, CENTER | 1 | ||||
| ? | MM0128 | CAPSCREW - M20 X 2.50 X 110 | 6 | ||||
| ? | EC7594 | FLAT WASHER, HARDENED - 3/8" | 8 | ||||
| ? | EG9144 | SPACER | 8 | ||||
| ? | MM0697 | LOCKNUT - M20 X 2.50 | 8 | ||||
| ? | MM0135 | CAPSCREW - M20 X 2.50 X 120 | 2 | ||||
| ? | MM0075 | CAPSCREW - M20 X 2.50 X 60 | 4 | ||||
| ? | MM0465 | FLAT WASHER - M20 | 4 | ||||
| ? | MM0475 | LOCKWASHER - M20 | 4 | ||||
| ? | MM0182 | NUT - M20 X 2.50 | 4 | ||||
| ? | 58E-54-27560 | PLATE | 1 | ||||
| ? | 58E-54-27790 | SHEET, DIMPLED | 1 |
