| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-54-60910 | PLATFORM, LH | 1 | ||||
| ? | EM9230 | PLATE, COVER | 1 | ||||
| ? | MM0606 | CAPSCREW - M10 X 1.50 X 30 | 4 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 4 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 4 | ||||
| ? | 58E-54-70060 | HANDRAIL | 1 | ||||
| ? | MM0618 | CAPSCREW - M12 X 1.75 X 30 | 8 | ||||
| ? | MM0472 | LOCKWASHER - M12 | 7 | ||||
| ? | MM0714 | FLAT WASHER, HARDENED - M12 | 42 | ||||
| ? | 58F-54-04911 | HANDRAIL | 1 | ||||
| ? | 58E-54-23260 | HANDRAIL, RH LADDER | 2 | ||||
| ? | MM0619 | CAPSCREW - M12 X 1.75 X 35 | 8 | ||||
| ? | 58F-80-04920 | MOUNT, LADDER | 1 | ||||
| ? | MM0620 | CAPSCREW - M12 X 1.75 X 40 | 11 | ||||
| ? | MM0694 | LOCKNUT - M12 X 1.75 | 8 | ||||
| ? | MM0179 | NUT - M12 X 1.75 | 8 | ||||
| ? | 58B-80-01940 | LADDER, DROP DOWN | 1 | ||||
| ? | MM0693 | LOCKNUT - M10 X 1.50 | 1 | ||||
| ? | 58B-80-04681 | LATCH, LADDER | 1 | ||||
| ? | 58B-80-01980 | LINK | 1 | ||||
| ? | 58B-54-03720 | PLATE, BENT | 1 | ||||
| ? | 58B-80-04681 | LATCH, LADDER | 1 | ||||
| ? | 58D-54-10530 | BUSHING, SHOULDER - M12 | 4 | ||||
| ? | 58E-80-12130 | SPACER | 1 | ||||
| ? | PC2325 | SPRING, RH | 1 | ||||
| ? | 58D-54-10410 | WASHER - 1/2" | 7 | ||||
| ? | MM0622 | CAPSCREW - M12 X 1.75 X 50 | 1 | ||||
| ? | 58E-09-01020 | SHOULDER BOLT - M12 X 50 | 1 | ||||
| ? | MM0462 | FLAT WASHER - M12 | 4 | ||||
| ? | WA0361 | FLAT WASHER, HARDENED - 5/8" | 4 | ||||
| ? | VH3402 | CAPSCREW - 5/8" - 11NC X 1 3/4" | 4 |
