| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE4687 | LOCKWASHER - 3/8" | 3 | ||||
| ? | VE4515 | FLAT WASHER - 3/8" | 2 | ||||
| ? | 58F-43-01650 | GROUND STRAP | 1 | ||||
| ? | VE2338 | CAPSCREW - 5/16" - 16NC X 3/4" | 1 | ||||
| ? | VE3918 | FLAT WASHER - 3/8" | 1 | ||||
| ? | VE4700 | NUT - 3/8" - 16NC | 1 | ||||
| ? | VE4640 | CAPSCREW - 3/8" - 16NC X 1 1/2" | 1 | ||||
| ? | 58F-43-01850 | GASKET | 1 | ||||
| ? | 58D-98-00920 | SEAL, TRIM | 1 | ||||
| ? | 58F-43-01130 | PANEL ASSEMBLY | 4 | ||||
| ? | 58F-43-01830 | CHANNEL | 1 | ||||
| ? | 58F-43-01030 | PANEL ASSEMBLY | 1 | ||||
| ? | VE4739 | CAPSCREW - 3/8" - 16NC X 1" | 1 | ||||
| ? | 58F-43-01940 | PANEL ASSEMBLY | 1 | ||||
| ? | 58F-43-01560 | LOCKNUT - 5/16" - 18NC | 1 | ||||
| ? | 58F-43-01530 | BUS BAR | 1 | ||||
| ? | 58F-43-01720 | BOLT - M6 X 12" | 1 | ||||
| ? | 58F-43-01820 | WASHER - M6 | 1 | ||||
| ? | 58F-43-01920 | LOCKWASHER - M6 | 1 | ||||
| ? | VE4696 | LOCKWASHER - 5/16" | 2 | ||||
| ? | BF0699 | CAPSCREW | 2 | ||||
| ? | VE5762 | FLAT WASHER - 5/16" | 2 |
