| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-06-18480 | COVER, WIRE | 1 | ||||
| ? | 58E-06-18390 | DUCT, WIRE | 1 | ||||
| ? | 58E-06-04160 | HUB, ETHERNET | 1 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 4 | ||||
| ? | 58E-06-30390 | CAPSCREW - M10 X 1.25 X 24 | 4 | ||||
| ? | 58E-06-10350 | NUT, RIBBED - #10 - 24NC | 24 | ||||
| ? | 58E-06-10360 | SCREW, FLANGE - #10 - 24NC X 3/4" | 8 | ||||
| ? | 58F-06-10920 | NAME PLATE - ORS HEATED HOSE | 1 | ||||
| ? | 58F-06-10910 | NAME PLATE - ORS POWER | 1 | ||||
| ? | 58E-06-40500 | TAG, ETHERNET HUB | 1 | ||||
| ? | 58E-06-20790 | NAME PLATE - VEC-92 BLOCK | 1 | ||||
| ? | EL7630 | NAME PLATE | 1 | ||||
| ? | 58E-06-04150 | RELAY - 24V, 75 AMP | 2 | ||||
| ? | XC2513 | BRACKET | 1 | ||||
| ? | SP8417 | FLAT WASHER - 1/4" | 2 | ||||
| ? | MM0581 | CAPSCREW - M6 X 1.00 X 16 | 2 | ||||
| ? | PB8256 | SCREW LOCK, FEMALE | 3 |
