| Наименование | Страница | Код страницы |
|---|---|---|
| AUXILIARY CONTROL CABINET - REAR WALL 1/2 | 178 | 68276 |
| AUXILIARY CTRL CABINET COMPONENTS - RH WALL 1/2 | 182 | 69037 |
| AUXILIARY CTRL CABINET COMPONENTS - LH WALL 1/2 | 186 | 69041 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | CONTROL BOX (1) | 1 | |||||
| ? | WB3770 | MACHINE SCREW - #10 - 24NC X 3/4" | 16 | ||||
| ? | 58E-06-18580 | PLATE | 2 | ||||
| ? | 58E-06-18590 | PLATE | 1 | ||||
| ? | 58E-06-18631 | PLATE | 1 | ||||
| ? | 58E-65-00082 | LABEL, VEC-89 | 1 | ||||
| ? | 58E-65-00092 | LABEL, VEC-90 | 1 | ||||
| ? | 58E-65-00102 | LABEL, VEC-91 | 1 | ||||
| ? | EC7458 | NAME PLATE - DL2 | 1 | ||||
| ? | EC7459 | NAME PLATE - DL3 | 1 | ||||
| ? | EC7460 | NAME PLATE - DL4 | 1 | ||||
| ? | EC7462 | NAME PLATE - DL1 | 1 | ||||
| ? | MM0459 | FLAT WASHER - M6 | 24 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 15 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 24 | ||||
| ? | 58E-65-00210 | LABEL, VEC-92 | 1 | ||||
| ? | MM0581 | CAPSCREW - M6 X 1.00 X 16 | 20 | ||||
| ? | MM0583 | CAPSCREW - M6 X 1.00 X 25 | 4 | ||||
| ? | MM0604 | CAPSCREW - M10 X 1.50 X 20 | 15 | ||||
| ? | 58E-06-18810 | PLATE | 1 | ||||
| ? | WB2200 | NAME PLATE - DLS | 1 | ||||
| ? | PB1006 | LATCH/KEEPER SET | 2 | ||||
| ? | PB3324 | BOOT, SWITCH | 1 | ||||
| ? | PC3010 | LIGHT, DOME | 4 | ||||
| ? | SR8325 | SWITCH, TOGGLE | 1 | ||||
| ? | NOTE: (1) NOT SERVICED AS AN ASSEMBLY. ORDER | ||||||
| ? | INDIVIDUAL COMPONENT PARTS. |
