| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-06-01880 | PLATE | 1 | ||||
| ? | MM0594 | CAPSCREW - M8 X 1.25 X 25 | 6 | ||||
| ? | MM0470 | LOCKWASHER - M8 | 6 | ||||
| ? | MM0460 | FLAT WASHER - M8 | 6 | ||||
| ? | MM0343 | MACHINE SCREW - M4 X 0.7 X 16 | 4 | ||||
| ? | MM0378 | LOCKWASHER, EXTERNAL TOOTH - M4 | 8 | ||||
| ? | MM0372 | NUT - M4 X 0.7 | 4 | ||||
| ? | PB6842 | HOOK, RUBBER | 1 | ||||
| ? | C1639 | CAPSCREW - 5/16" - 18NC X 2" | 1 | ||||
| ? | VN9951 | LOCKNUT - 5/16" - 18NC | 1 | ||||
| ? | 58E-06-02091 | RELAY BOX ASSEMBLY | 1 | ||||
| ? | 58E-06-01311 | HARNESS, WIRING - ISOLATION BOX INTERNAL | 1 | ||||
| ? | PC2528 | SWITCH, LOCKOUT | 1 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 2 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 2 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 5 | ||||
| ? | HD8390 | FLAT WASHER, COPPER - # 10 | 2 | ||||
| ? | VN7121 | MACHINE SCREW - # 10 - 24NC X 1/2" | 3 | ||||
| ? | VC5344 | FLAT WASHER - #10 | 3 | ||||
| ? | 58E-06-01890 | BUS BAR | 1 | ||||
| ? | 58E-06-10200 | BUS BAR | 1 | ||||
| ? | 58E-06-10100 | BUS BAR | 1 | ||||
| ? | 58E-06-10420 | BUS BAR | 1 | ||||
| ? | DF3500 | LOCKNUT - 1/2" - 13NC | 4 | ||||
| ? | MM0578 | CAPSCREW - M6 X 1.00 X 10 | 4 | ||||
| ? | SD4235 | LOCKWASHER, EXTERNAL TOOTH - 1/4" | 4 |
