| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PC1137 | DISPLAY, PLM SCOREBOARD | 2 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 18 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 18 | ||||
| ? | XB1837 | BRACKET, MOUNTING | 2 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 16 | ||||
| ? | 58E-06-05762 | HARNESS, WIRING - PLM SCOREBOARD LH/RH | 1 | ||||
| ? | 58D-90-00700 | CLAMP, CUSHIONED - 7/16" | 30 | ||||
| ? | WB3917 | NUT, COUPLING | 2 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 2 | ||||
| ? | TY8375 | SPACER | 3 | ||||
| ? | 58E-06-05532 | HARNESS, WIRING - AUX BOX/PLM SCOREBOARD | 1 | ||||
| ? | WB3097 | CLAMP, CUSHIONED - 1/2" | 12 |
