Содержание Dump Trucks Komatsu AFE77-U 830E-5 S/N A50066 - A50067 COPPER MOUNTAIN(AFE77-U)
AUTOMATIC LUBRICATION SYSTEM 5/5(746 : 68220)
Номер на схеме Каталожный номер Название Количество Детали
? WB1300 CLAMP, CUSHIONED - 5/8" 66
? EM1393 SPACER 15
? MM0178 NUT - M10 X 1.50 26
? MM0471 LOCKWASHER - M10 26
? MM0461 FLAT WASHER - M10 26
? WB3855 CLAMP, CUSHIONED - 13/16" 35
? WB0454 FITTING, STRAIGHT 2
? WB0284 FITTING, ELBOW - 45 DEG 2
? MM0606 CAPSCREW - M10 X 1.50 X 30 4
? DC5608 NIPPLE 2
? C1231 COUPLING, PIPE 2
? WB0252 FITTING, ELBOW - 90 DEG 2
? WB0574 FITTING, STRAIGHT 2
