| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58E-54-30646 | DOOR - RH | 1 | ||||
| ? | 58E-54-23430 | BOLT - M8 X 20 | 11 | ||||
| ? | 58E-54-08372 | DOOR, HINGE | 1 | ||||
| ? | 58E-54-10101 | WINDOW ASSEMBLY | 1 | ||||
| ? | 58E-98-10500 | • CHANNEL, GLASS | 1 | ||||
| ? | 58E-98-10510 | • COVER, SCREW | 1 | ||||
| ? | 58E-98-10520 | • WIPE, GLASS | 1 | ||||
| ? | 58E-98-10530 | • FILLER | 1 | ||||
| ? | 58E-98-10720 | • GLASS | 1 | ||||
| ? | SM2406 | SCREW, SELF-TAPPING - #6 - 32NC X 3/8" | 18 | ||||
| ? | 58E-54-31172 | LATCH, DOOR - RH | 1 | ||||
| ? | 58E-54-31430 | SEAL, WINDOW | 1 | ||||
| ? | 58E-54-30663 | DOOR, GRAB HANDLE - RH | 1 | ||||
| ? | 58E-54-15450 | PAD, DEADENING | 2 | ||||
| ? | SD4235 | LOCKWASHER, EXTERNAL TOOTH - 1/4" | 4 | ||||
| ? | 58E-09-10180 | SCREW, TRUSS | 3 | ||||
| ? | 58E-09-00180 | SCREW, TRUSS | 1 | ||||
| ? | 58E-09-00160 | SCREW - #6 - 32NC X 1/4" | 6 | ||||
| ? | 58E-54-09131 | HANDLE, PUSH BUTTON | 1 | ||||
| ? | MM0582 | • CAPSCREW - M6 X 1.00 X 20 | 7 | ||||
| ? | MM0176 | • NUT - M6 X 1.00 | 1 | ||||
| ? | 58E-98-10070 | • GASKET | 2 | ||||
| ? | XB0815 | PLATE | 1 | ||||
| ? | 58E-54-22680 | SCREW - M6 X 20 | 3 | ||||
| ? | 58E-54-31710 | REGULATOR, WINDOW - RH | 4 | ||||
| ? | 58E-54-09173 | SEAL, DOOR | 1 | ||||
| ? | 58E-54-31461 | PLATE | 1 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 15 | ||||
| ? | MM0459 | FLAT WASHER - M6 | 19 | ||||
| ? | MM0579 | CAPSCREW - M6 X 1.00 X 12 | 11 | ||||
| ? | MM0358 | MACHINE SCREW - M6 X 1.00 X 16 | 2 | ||||
| ? | 58E-54-23360 | BRACKET, REGULATOR MOTOR | 1 | ||||
| ? | 58E-54-23520 | BRACKET, REGULATOR LOWER | 1 | ||||
| ? | 58E-54-09392 | BRACKET, WINDOW LIFT | 1 | ||||
| ? | 58E-54-09452 | • BRACKET, WINDOW STOPPER | 1 | ||||
| ? | 58E-54-23371 | • BRACKET, REGULATOR UPPER | 1 | ||||
| ? | SM2261 | • GASKET | 2 | ||||
| ? | EM7654 | • BUSHING, NYLON | 4 |
