| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EJ2737 | HOUSING | 1 | ||||
| ? | TY8879 | PLUG, VENT | 1 | ||||
| ? | PC2588 | BEARING, PISTON | 1 | ||||
| ? | PC2587 | BEARING, ROD | 1 | ||||
| ? | EK8138 | RETAINER, BEARING | 1 | ||||
| ? | VN9140 | CAPSCREW - 3/4" - 10NC X 4" | 24 | ||||
| ? | WA0362 | FLAT WASHER - 3/4" | 24 | ||||
| ? | PC0626 | SEAL, ROD BUFFER - 14" (1) | 1 | ||||
| ? | PC0625 | SEAL, ROD DOUBLE LIP - 14" (1) | 1 | ||||
| ? | PC0627 | SEAL, WIPER - 14" (1) | 1 | ||||
| ? | EL7310 | PISTON | 1 | ||||
| ? | VM0313 | PLUG | 4 | ||||
| ? | PB2194 | CHARGING VALVE ASSEMBLY (1)/(2) | 1 | ||||
| ? | TD7179 | • CORE, VALVE | 1 | ||||
| ? | TR9993 | • CAP, VALVE | 1 | ||||
| ? | TF1144 | • O-RING, HOUSING | 1 | ||||
| ? | WA0052 | • O-RING, VALVE STEM | 1 | ||||
| ? | VD5076 | GASKET, FLAT (1)/(2) | 1 | ||||
| ? | PLATE, DANGER | 2 | |||||
| ? | WA3134 | SCREW, DRIVE - #6 X 3/16" | 8 | ||||
| ? | WA0180 | O-RING (1) | 1 | ||||
| ? | PC0673 | RING, BACKUP (1) | 1 | ||||
| ? | TZ8637 | PLUG, SENSOR | 1 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | AK4063 | SUSPENSION OIL MIXTURE - 5 GAL | 6 | ||||
| ? | AK4064 | SUSPENSION OIL MIXTURE - 55 GAL | 1 | ||||
| ? | 58F-RS-AK031 | NOTE: (1) INCLUDED IN 58F-RS-AK031 REAR SUSPENSION | |||||
| ? | OVERHAUL KIT. | ||||||
| ? | RK1887 | (2) INCLUDED IN RK1887 CHARGING VALVE KIT. |
