| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | XA4291 | FILTER, SAFETY | 2 | ||||
| ? | XA4292 | FILTER, PRIMARY | 2 | ||||
| ? | 58F-02-00150 | COVER | 2 | ||||
| ? | XA4293 | CHAIN | 2 | ||||
| ? | XA5012 | CONNECTOR, CHAIN | 4 | ||||
| ? | 58F-02-00010 | CUP ASSEMBLY | 3 | ||||
| ? | XA3920 | • CUP | 3 | ||||
| ? | CD9709 | • CLAMP, WORM DRIVE | 3 | ||||
| ? | PB1551 | • TUBE | 3 | ||||
| ? | VG9486 | • VALVE, DUST CUP | 3 | ||||
| ? | VS2190 | O-RING | 3 | ||||
| ? | VP0359 | CLAMP | 3 | ||||
| ? | VJ4028 | BODY, LOWER | 1 | ||||
| ? | VS2194 | GASKET (SHORT STRIPS) | 2 | ||||
| ? | VS2193 | GASKET (LONG STRIPS) | 2 | ||||
| ? | BODY, UPPER (1) | 1 | |||||
| ? | VS2195 | CAPSCREW | 22 | ||||
| ? | VS2196 | NUT | 34 | ||||
| ? | NOTE: (1) NOT SERVICED SEPARATELY. |
