| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | XB2935 | STEP, GRILLE | 2 | ||||
| ? | MM0619 | CAPSCREW - M12 X 1.75 X 35 | 4 | ||||
| ? | MM0714 | FLAT WASHER, HARDENED - M12 | 44 | ||||
| ? | MM0472 | LOCKWASHER - M12 | 31 | ||||
| ? | MM0179 | NUT - M12 X 1.75 | 22 | ||||
| ? | XB2826 | HANDRAIL | 1 | ||||
| ? | 58F-80-40160 | HANDRAIL | 1 | ||||
| ? | 58F-80-40140 | HANDRAIL | 1 | ||||
| ? | MM0620 | CAPSCREW - M12 X 1.75 X 40 | 20 | ||||
| ? | 58F-54-20360 | GATE, LH | 1 | ||||
| ? | MM0623 | CAPSCREW - M12 X 1.75 X 60 | 4 | ||||
| ? | MM0617 | CAPSCREW - M12 X 1.75 X 25 | 4 | ||||
| ? | 58F-54-30000 | PLATE, BENT | 1 | ||||
| ? | 58F-54-05460 | PLATE, BENT | 1 | ||||
| ? | PC2325 | SPRING, RH | 1 | ||||
| ? | 58F-54-05470 | SPACER | 1 | ||||
| ? | MM0613 | CAPSCREW - M10 X 1.50 X 80 | 1 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 1 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 2 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 1 | ||||
| ? | 58F-54-05520 | HINGE | 2 | ||||
| ? | 58F-54-30070 | BLOCK, SPACER | 2 | ||||
| ? | MM0462 | FLAT WASHER - M12 | 10 |
