| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 6219-51-1000 | Pump Assembly | 1 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | PML160-11600 | • Gear and Case Assembly | 1 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | PML150-08400 | • • Case Assembly | 1 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | • • • Case | 1 | SN: 505077- KIT-FLAG: _- SCC: C1 SERIALNO: 505077- |
||||
| ? | PML130-00220 | • • • Bushing | 1 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | PML154-09500 | • • Gear Assembly, Drive | 1 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | • • • Gear | 1 | SN: 505077- KIT-FLAG: _- SCC: C1 SERIALNO: 505077- |
||||
| ? | • • • Shaft, Drive | 1 | SN: 505077- KIT-FLAG: _- SCC: C1 SERIALNO: 505077- |
||||
| ? | PML124-06600 | • • Gear | 1 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | PML156-07700 | • • Gear Assembly, Driven | 2 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | • • • Gear | 2 | SN: 505077- KIT-FLAG: _- SCC: C1 SERIALNO: 505077- |
||||
| ? | • • • Bushing | 2 | SN: 505077- KIT-FLAG: _- SCC: C1 SERIALNO: 505077- |
||||
| ? | PML152-07400 | • • Cover Assembly | 1 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | PML152-07500 | • • • Cover Assembly | 1 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | • • • • Cover | 1 | SN: 505077- KIT-FLAG: _- SCC: C1 SERIALNO: 505077- |
||||
| ? | • • • • Bushing | 1 | SN: 505077- KIT-FLAG: _- SCC: C1 SERIALNO: 505077- |
||||
| ? | PML112-00411 | • • • Shaft | 2 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | PML142-01700 | • • • Ring | 1 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | PMMF14-0227 | • • Bolt | 5 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | 01437-01245 | Bolt | 2 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | 01437-01280 | Bolt | 1 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | 07000-E3050 | O-ring | 1 | SN: 505077- KIT-FLAG: S- SCC: SERIALNO: 505077- |
|||
| ? | 6219-51-2700 | Valve Assembly | 1 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | 6219-51-2710 | • Body | 1 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | 6219-51-2740 | • Plug | 1 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | 6219-51-2730 | • Valve | 1 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | 6219-51-2750 | • Spring | 1 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | 6215-51-1780 | Gasket | 1 | SN: 505077- KIT-FLAG: S- SCC: SERIALNO: 505077- |
|||
| ? | 01437-01030 | Bolt | 2 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
|||
| ? | 01437-01060 | Bolt | 1 | SN: 505077- KIT-FLAG: _- SCC: SERIALNO: 505077- |
