Содержание Excavators Komatsu PC200LC-8M0 S/N 400001-UP(0000650C)
Cab, Floor, Console, R.H. (#400001-400001)(K019044 : K1110-205044)
Номер на схеме Каталожный номер Название Количество Детали
? 20Y-43-41314 Frame 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01010-D1230 Bolt 4
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01643-71232 Washer 4
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 20Y-43-41631 Sheet 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 22U-43-23251 Sheet 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 22U-43-23290 Clip 2
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 20Y-43-41324 Cover 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 20Y-43-41661 Sheet 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01010-80616 Bolt 4
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01643-30623 Washer 4
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 20Y-43-41290 Collar 4
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 20Y-43-41332 Cover 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01245-00616 Screw 2
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01643-70623 Washer 2
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01010-80616 Bolt 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01643-30623 Washer 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01435-00612 Bolt 2
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 20Y-43-41290 Collar 5
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 20Y-43-41353 Cover 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01245-00616 Screw 2
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01643-70623 Washer 2
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 20Y-43-41290 Collar 2
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01245-00616 Screw 3
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01643-70623 Washer 3
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 09415-02512 Cap 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 08086-20000 Switch, Starting 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 20Y-43-41740 Plate 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 20Y-43-41750 Washer 3
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 20Y-43-41790 Washer 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 20Y-43-41671 Sheet 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 08034-20519 Band 2
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 22U-06-22380 Potentiometer 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 22U-06-22460 Spring 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 20Y-43-41781 Knob 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 20Y-06-42110 Switch, Lock 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 20Y-06-42121 Switch, Lamp 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 20Y-06-42190 Cover 3
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 20Y-06-16920 Wiring Harness 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 08034-20414 Band 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01023-10508 Screw 5
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01601-20513 Washer 5
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 22U-43-23260 Clip 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 04434-51710 Clip 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01010-81016 Bolt 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01643-31032 Washer 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 04434-51410 Clip 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01010-81016 Bolt 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
? 01643-31032 Washer 1
SN: 400001-400001
KIT-FLAG: _-
SCC:
SERIALNO: 400001-400001
