| Наименование | Страница | Код страницы |
|---|---|---|
| ALTERNATOR - BRUSH HOLDER ASSEMBLY VJ1024 | 640 | 64030 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | GE1144 | FRAME, HEAD | 1 | ||||
| ? | XA4108 | HOUSING, INLET | 1 | ||||
| ? | VE3027 | FLAT WASHER - 3/8" | |||||
| ? | VE4641 | CAPSCREW - 3/8" - 16NC X 1 1/4" | |||||
| ? | XA4109 | HOUSING, OUTLET | 1 | ||||
| ? | GE1082 | IMPELLER | 1 | ||||
| ? | VE5185 | FLAT WASHER - 1/2" | 16 | ||||
| ? | VE4998 | CAPSCREW - 1/2" - 13NC X 4 1/2" | |||||
| ? | GE1156 | HUB | 1 | ||||
| ? | VE3620 | PIN, DOWEL | 2 | ||||
| ? | VE4500 | CAPSCREW - 3/8" - 16NC X 1 3/4" | |||||
| ? | TC1233 | NUT - 3/8" - 16NC | |||||
| ? | VE4641 | CAPSCREW - 3/8" - 16NC X 1 1/4" | |||||
| ? | VJ9656 | ADHESIVE, RTV | |||||
| ? | GE1155 | SENSOR, SPEED | 1 | ||||
| ? | VE5184 | FLAT WASHER | 6 | ||||
| ? | C1630 | CAPSCREW - 5/8" - 11NC X 2" | 6 | ||||
| ? | GE0141 | CAPSCREW - 5/8" - 11NC X 2 1/4" | 6 | ||||
| ? | VE4631 | FLAT WASHER | 6 | ||||
| ? | VJ1024 | BRUSH HOLDER ASSEMBLY (SEE INDEX) | 1 | 64030 |
