Номер на схеме	Каталожный номер	Название	Количество
?	XA4250	BUS BAR	1
?	XA4328	BUS BAR	4
?	XA4249	BUS BAR	5
?	GE0579	STUD	2
?	VE4699	LOCKWASHER - 1/2"
?	VE4698	NUT - 1/2" - 13NC
?	VE4519	FLAT WASHER - 1/2"
?	GE1409	BUS BAR	2
?	PB3348	INSULATOR	2
?	GE1384	STUD	56
?	VE4490	FLAT WASHER - 1/2"
?	VE3918	WASHER
?	VE4687	LOCKWASHER - 3/8"
?	VE4515	FLAT WASHER - 3/8"
?	TC1233	NUT - 3/8" - 16NC
?	VE4640	CAPSCREW - 3/8" - 16NC X 1 1/2"
?	XA5985	INVERTER, IGBT (+) (HIGH THERMAL)	14
?	58B-43-00410	• GASKET	1
?	XA5986	INVERTER, IGBT (-) (HIGH THERMAL)	14
?	58B-43-00410	• GASKET	1
?	XA4290	FUSE, IGBT	26
?	XA4876	CAPACITOR, FILTER	10
?	58B-43-00660	BUS BAR	5
?	BF0543	CAPSCREW - 5/16" - 18NC X 2 1/2"
?	GE1381	FLAT WASHER - 5/16"
?	GE1383	FLAT WASHER - 11/16"
?	VE4696	LOCKWASHER - 5/16"
?	VE0513	NUT - 5/16" - 18NC
?	GE1412	BUS BAR, VERTICAL	5
?	58B-43-00270	TERMINAL	2
?	VE4518	CAPSCREW - 1/2" - 13NC X 1 1/2"	20
?	XA5273	SPACER	10
?		(FOR VIEWS A-A, B-B & C-C, SEE THE FOLLOWING PAGES.)
