Содержание Dump Trucks Komatsu AFE62-AQ 930E-4SE S/N A31450, A31500, A31576, A31578 & A31605 - A31607 BLOOM LAKE(AFE62-AQ)
FOOTREST AND FLOOR MATS(184 : 41977)
Номер на схеме Каталожный номер Название Количество Детали
? EK2782 FLOOR MAT, FRONT 1
? SM5435 FLOOR MAT, THRESHOLD 2
? EK2817 FLOOR MAT, SEAT 2
? EK2811 FLOOR MAT, REAR 1
? SM5048 FOOTREST 1
? 27705R1 SCREW, TAP - 1/4" - 14NC X 1" 4
? SM5434 FLOOR MAT, FOOTREST 1
