| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | XC1552 | CAMERA ASSEMBLY | 1 | ||||
| ? | 1401385H1 | • CAMERA | 1 | ||||
| ? | XB9043 | • SHEET, BENT | 1 | ||||
| ? | XC0406 | • SHEET, BENT | 1 | ||||
| ? | MM0582 | • CAPSCREW - M6 X 1.00 X 20 | 4 | ||||
| ? | MM0469 | • LOCKWASHER - M6 | 4 | ||||
| ? | 01643-30623 | • WASHER - M6 | 4 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 3 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 48 | ||||
| ? | WB1301 | CLAMP, CUSHIONED - 1/4" | 1 | ||||
| ? | MM0604 | CAPSCREW - M10 X 1.50 X 20 | 2 | ||||
| ? | 01643-31032 | WASHER - M10 | 5 | ||||
| ? | WB3922 | CLAMP, CUSHIONED - 11/16" | 4 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 45 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 45 | ||||
| ? | EM1398 | SPACER | 1 | ||||
| ? | WB1302 | CLAMP, CUSHIONED - 5/16" | 135 | ||||
| ? | TY8375 | SPACER | 15 | ||||
| ? | XB9046 | CAMERA ASSEMBLY | 3 | ||||
| ? | 1401385H1 | • CAMERA | 1 | ||||
| ? | XB9043 | • SHEET, BENT | 1 | ||||
| ? | XB9045 | • MOUNT | 1 | ||||
| ? | MM0582 | • CAPSCREW - M6 X 1.00 X 20 | 4 | ||||
| ? | 01643-30623 | • WASHER - M6 | 4 | ||||
| ? | MM0604 | • CAPSCREW - M10 X 1.50 X 20 | 1 | ||||
| ? | 01643-31032 | • WASHER - M10 | 1 | ||||
| ? | WB1301 | • CLAMP, CUSHIONED - 1/4" | 1 | ||||
| ? | MM0594 | CAPSCREW - M8 X 1.25 X 25 | 6 | ||||
| ? | MM0593 | CAPSCREW - M8 X 1.25 X 20 | 4 | ||||
| ? | MM0470 | LOCKWASHER - M8 | 10 | ||||
| ? | 01643-30823 | WASHER - M8 | 10 | ||||
| ? | PC3347 | CABLE (1) | 1 | ||||
| ? | PC3351 | CABLE (2) | 1 | ||||
| ? | PC3345 | CABLE | 1 | ||||
| ? | PC3344 | CABLE | 1 | ||||
| ? | PC3347 | CABLE | 1 | ||||
| ? | NOTE: (1) USED FOR LH LADDER CONFIGURATION ONLY. | ||||||
| ? | (2) USED FOR RH LADDER CONFIGURATION ONLY. |
