| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | WB2452 | DECAL, RADIATOR CAP WARNING (TOP OF GRILLE) | 1 | ||||
| ? | 09690-B1800 | DECAL, "KOMATSU" (FRONT AND SIDES OF BODY) | 3 | ||||
| ? | 09690-P0710 | DECAL, "KOMATSU" (DRIVER'S DOOR) | 1 | ||||
| ? | WB3341 | DECAL, 930E (L.H. SIDE OF BODY) | 1 | ||||
| ? | WB3342 | DECAL, 930E (R.H. SIDE OF BODY) | 1 | ||||
| ? | WB2790 | CHART, LUBE (BEHIND R.H. LADDER) | 1 | ||||
| ? | WB2442 | DECAL, WELDING CAUTION (BATTERY CONTROL BOX) | 1 | ||||
| ? | WB3777 | DECAL, HIGH VOLTAGE WARNING (CONTROL CABINET DOORS) | 3 | ||||
| ? | WB2447 | DECAL, ACCUMULATOR WARNING (ON ACCUMULATORS INSIDE BRAKE CABINET) | 2 | ||||
| ? | WB2441 | DECAL, BATTERY DANGER (BATTERY BOX) | 1 | ||||
| ? | WB2225 | DECAL, CAPACTOR CHARGE LIGHT (CONTROL CABINETS) | 2 | ||||
| ? | WB2224 | DECAL, INFORMATION DISPLAY (CONTROL CABINET) | 1 | ||||
| ? | WB3217 | DECAL, STORED ENERGY HAZARD (BATTERY BOX) | 1 | ||||
| ? | WB3343 | DECAL, 930E (R.H. FRONT OF CANOPY) | 1 | ||||
| ? | 09690-F1000 | DECAL, "KOMATSU" (FRONT OF GRILLE) | 1 | ||||
| ? | EM7216 | PLATE, MOUNTING | 1 | ||||
| ? | MM0042 | CAPSCREW - M10 X 1.50 X 25 | 5 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 5 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | WB2711 | DECAL, TOW BUMPER CAUTION (FRONT BUMPER) (1) | 1 | ||||
| ? | 58F-80-00010 | NOTE: (1) INCLUDED IN TOW BUMPER KIT. |
