| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EJ0608 | PLATE | 1 | ||||
| ? | EF6610 | GASKET | 1 | ||||
| ? | C1648 | CAPSCREW - 3/4" - 10NC X 3" | 2 | ||||
| ? | C1542 | LOCKWASHER - 3/4" | 2 | ||||
| ? | C1551 | FLAT WASHER - 3/4" | 2 | ||||
| ? | EL7410 | MOUNT, POWER CABLES | 1 | ||||
| ? | EL7409 | GASKET | 1 | ||||
| ? | MM0086 | CAPSCREW - M16 X 2.00 X 60 | 4 | ||||
| ? | MM0474 | LOCKWASHER - M16 | 14 | ||||
| ? | MM0464 | FLAT WASHER - M16 | 14 | ||||
| ? | EK0748 | SWITCH, BLOWER PRESSURE | 1 | ||||
| ? | EL1727 | • HARNESS | 1 | ||||
| ? | PB4673 | • SWITCH, BLOWER PRESSURE | 1 | ||||
| ? | VA7927 | TUBE, NYLON | 1 | ||||
| ? | TA0603 | FITTING, NYLON | 1 | ||||
| ? | H8136 | CAPSCREW - 1/4" - 20NC X 1/2" | 4 | ||||
| ? | C5774 | LOCKWASHER - 1/4" | 4 | ||||
| ? | MM0181 | NUT - M16 X 2.00 | 10 | ||||
| ? | EC1090 | STUD, THREADED - M16 X 2.00 | 10 | ||||
| ? | XB1109 | CLAMP, CABLE | 10 | ||||
| ? | EK5647 | HARNESS, BLOWER PRESSURE SWITCH | 1 | ||||
| ? | EK6383 | BUS BAR | 2 | ||||
| ? | EK6384 | BUS BAR | 2 | ||||
| ? | EK6385 | BUS BAR | 2 | ||||
| ? | VC8762 | CAPSCREW - 3/8" - 16NC X 1 1/2" | 24 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 27 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 54 | ||||
| ? | TC1233 | NUT - 3/8" - 16NC | 27 | ||||
| ? | WB3092 | CLAMP, CUSHIONED - 7/8" | 1 | ||||
| ? | WB1304 | CLAMP, CUSHIONED - 9/16" | 2 | ||||
| ? | EM8292 | HARNESS, WHEEL SPEED | 1 | ||||
| ? | EL7726 | BRACKET | 1 | ||||
| ? | VC1387 | CAPSCREW - 1/2" - 13NC X 1" | 2 | ||||
| ? | TR6008 | FLAT WASHER - 1/2" | 2 |
