Содержание Dump Trucks Komatsu AFE62-BA 930E-4SE S/N A31778 - A31780 & A31796 - A31798 ANTAMINA(AFE62-BA)
RIM ASSEMBLY, OUTER DUAL SMART RIM(120 : 43191)
Номер на схеме Каталожный номер Название Количество Детали
? XC2400 SMART RIM ASSEMBLY 1
? XC2399 • RING, LOCK - 63" 1
? AK4791 • BAND, BEAD SEAT - 63" 1
? AK5178 • RING, SIDE 2
? XC2398 • RIM BASE - 63" X 36" 1
? WB1139 O-RING - 63" 1
? (QUANTITIES SHOWN ARE FOR ONE WHEEL ONLY.)
