Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
PB9923 |
MOTOR, WIPER - 24 VOLT |
1 |
|
|
|
|
? |
MM0592 |
CAPSCREW - M8 X 1.25 X 16 |
5 |
|
|
|
|
? |
MM0712 |
FLAT WASHER - M8 (HARDENED) |
14 |
|
|
|
|
? |
MM0470 |
LOCKWASHER - M8 |
5 |
|
|
|
|
? |
SM4345 |
PLATE |
1 |
|
|
|
|
? |
MM0581 |
CAPSCREW - M6 X 1.00 X 16 |
3 |
|
|
|
|
? |
MM0711 |
FLAT WASHER - M6 (HARDENED) |
3 |
|
|
|
|
? |
MM0469 |
LOCKWASHER - M6 |
3 |
|
|
|
|
? |
PB9926 |
WIPER LINKAGE ASSEMBLY (SEE INDEX) |
1 |
|
42777 |
|
|
? |
PC1823 |
ARM, WET WIPER |
2 |
|
|
|
|
? |
XA2095 |
NOZZLE |
2 |
|
|
|
|
? |
PB9925 |
BLADE, WIPER |
2 |
|
|
|
|
? |
MM0022 |
CAPSCREW - M8 X 1.25 X 20 |
4 |
|
|
|
|
? |
MM0460 |
FLAT WASHER - M8 |
4 |
|
|
|
|
? |
EG0735 |
TEE, HOSE |
1 |
|
|
|
|
? |
TF6380 |
GROMMET, RUBBER |
2 |
|
|
|
|
? |
SM4477 |
HOSE |
2 |
|
|
|
|
? |
EG3904 |
HOSE |
1 |
|
|
|
|
? |
|
NUT - M8 X 1.25 (1) |
1 |
|
|
|
|
? |
|
COVER (1) |
1 |
|
|
|
|
? |
|
NUT - M20 X 1.00 (1) |
1 |
|
|
|
|
? |
|
WASHER (1) |
1 |
|
|
|
|
? |
|
WASHER (1) |
1 |
|
|
|
|
? |
|
NOTE: (1) NOT SERVICED SEPARATELY. |
|
|
|
|
|
? |
|
ORDER HARDWARE KIT XA3071. |
|
|
|
|
