| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EK8720 | CONDENSER | 1 | ||||
| ? | C1613 | CAPSCREW - 1/2" - 13NC X 1 1/4" | 12 | ||||
| ? | WA4728 | FLAT WASHER - 1/2" (HARDENED) | 24 | ||||
| ? | DF3500 | LOCKNUT - 1/2" - 13NC | 12 | ||||
| ? | 58B-07-00000 | HOSE | 1 | ||||
| ? | WA1732 | O-RING | 1 | ||||
| ? | WB3922 | CLAMP, CUSHIONED - 11/16" | 12 | ||||
| ? | C1605 | CAPSCREW - 3/8" - 16NC X 1 3/4" | 1 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 1 | ||||
| ? | 892124C1 | SPACER | 1 | ||||
| ? | 58B-07-00040 | HOSE | 1 | ||||
| ? | WA1731 | O-RING | 1 | ||||
| ? | 58B-07-11100 | MOUNT, CONDENSER | 1 | ||||
| ? | C1616 | CAPSCREW - 1/2" - 13NC X 2" | 4 | ||||
| ? | DA0557 | WASHER | 8 | ||||
| ? | VY9850 | MOUNT, RUBBER | 4 | ||||
| ? | WB1300 | CLAMP, CUSHIONED - 5/8" | 8 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 11 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 11 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 13 | ||||
| ? | EK9883 | SPACER | 2 | ||||
| ? | 58E-09-00010 | BRACKET | 1 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 2 | ||||
| ? | WB3093 | CLAMP, CUSHIONED - 1" | 1 | ||||
| ? | WB1302 | CLAMP, CUSHIONED - 5/16" | 1 | ||||
| ? | 08193-21012 | CLIP | 1 |
