| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | XA2375 | KIT, GAP HIDER | 1 | ||||
| ? | XA5621 | CONTACT ASSEMBLY, HORN | 1 | ||||
| ? | XA4890 | SPRING | 1 | ||||
| ? | BF5169 | KIT, ROD AND PAWL | 1 | ||||
| ? | BF5170 | KIT, TILT BOLT | 1 | ||||
| ? | VE4299 | COVER | 1 | ||||
| ? | BF5171 | KIT, TILT LEVER | 1 | ||||
| ? | BF2071 | KIT, TILT STOP | 1 | ||||
| ? | BF5176 | KIT, EXTENSION SPRING | 1 | ||||
| ? | XA2376 | KIT, COVER (UPPER & LOWER) | 1 | ||||
| ? | BF5173 | KIT, KNOB | 1 | ||||
| ? | BF5174 | KIT, TELESCOPE LINK | 1 | ||||
| ? | BF5175 | NUT | 1 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | VE4309 | BRACKET, MOUNTING | 1 | ||||
| ? | VE4310 | CAPSCREW - 3/8" - 24NF | 2 | ||||
| ? | VE4311 | LOCKWASHER - 3/8" | 2 | ||||
| ? | BF2089 | KIT, GREASE | 1 |
