| Наименование | Страница | Код страницы |
|---|---|---|
| STEERING COLUMN ASSEMBLY XB8878 | 220 | 41730 |
| RETARDER LEVER ASSEMBLY EK9211 | 222 | 60466 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EK9211 | RETARDER LEVER ASSEMBLY (SEE INDEX) | 1 | 60466 | |||
| ? | 58F-40-00180 | STEERING COLUMN ASSEMBLY | 1 | ||||
| ? | XB8878 | • COLUMN, STEERING (SEE INDEX) | 1 | 41730 | |||
| ? | 58F-54-00020 | • MULTI-FUNCTION SWITCH ASSEMBLY | 1 | ||||
| ? | WB3105 | • FLAT WASHER - M7 | 2 | ||||
| ? | WB3104 | • FLAT WASHER - M5 | 2 | ||||
| ? | WB3103 | • LOCKWASHER - M5 | 2 | ||||
| ? | 58F-09-00000 | • CAPSCREW - M5 X .8 X 45 | 2 | ||||
| ? | 08021-00400 | • CONNECTOR | 1 | ||||
| ? | SD4245 | LOCKWASHER - #10 (EXTERNAL TOOTH) | 4 | ||||
| ? | HD6007 | MACHINE SCREW - #10 - 24NC X 3/4" | 4 | ||||
| ? | EK4275 | ANGLE, FORMED | 1 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | SM6037 | HARNESS, THROTTLE PEDAL | 1 | ||||
| ? | VZ4843 | TYRAP | 1 |
