| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | SM2701 | LEXAN OVERLAY | 1 | ||||
| ? | EL5798 | MOUNT, RADIO | 1 | ||||
| ? | PC2886 | RADIO | 1 | ||||
| ? | EJ1556 | HARNESS, RADIO | 1 | ||||
| ? | EK4230 | SUPPORT | 1 | ||||
| ? | PC0441 | ALARM, AUDIBLE | 1 | ||||
| ? | EK7524 | POTENTIOMETER (DIMMER CONTROL) | 1 | ||||
| ? | PB5957 | KNOB | 1 | ||||
| ? | SF9896 | KNIFE, DISCONNECT | 1 | ||||
| ? | DL4172 | SLEEVE, INSULATING | 1 | ||||
| ? | WB3103 | LOCKWASHER - M5 | 1 | ||||
| ? | WB3104 | FLAT WASHER - M5 | 1 | ||||
| ? | MM0373 | NUT - M5 X .8 | 1 | ||||
| ? | NOTE: MODULE NOT SERVICED AS AN ASSEMBLY. | ||||||
| ? | ORDER INDIVIDUAL COMPONENT PARTS. |
