| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | WB0303 | FITTING, ELBOW - 45 DEG | 1 | ||||
| ? | HA8269 | HOSE | 1 | ||||
| ? | WA3484 | CLAMP, HYDRA ZORB | 1 | ||||
| ? | XB5537 | BRACKET | 1 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 2 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 2 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 2 | ||||
| ? | XB8518 | BOX, FUELING | 1 | ||||
| ? | PC3115 | DRAW LATCH, ADJUSTABLE | 1 | ||||
| ? | TF6246 | MACHINE SCREW - #8 - 32NC X 5/8" | 3 | ||||
| ? | TF6248 | FLAT WASHER - #8 | 3 | ||||
| ? | VM9910 | LOCKWASHER - #8 | 3 | ||||
| ? | TV2179 | NUT - #8 - 32NC | 3 | ||||
| ? | SR6528 | MACHINE SCREW - #12 - 24NC X 3/4" | 2 | ||||
| ? | DF3445 | FLAT WASHER - #12 | 2 | ||||
| ? | VD2047 | LOCKWASHER - #12 | 2 | ||||
| ? | TR8580 | NUT - #12 - 24NC | 2 | ||||
| ? | WB0479 | FITTING, STRAIGHT | 1 | ||||
| ? | PB2154 | RECEIVER | 1 | ||||
| ? | PB2020 | CAP ASSEMBLY | 1 | ||||
| ? | MM0594 | CAPSCREW - M8 X 1.25 X 25 | 1 | ||||
| ? | MM0460 | FLAT WASHER - M8 | 1 | ||||
| ? | MM0470 | LOCKWASHER - M8 | 1 | ||||
| ? | MM0177 | NUT - M8 X 1.25 | 1 | ||||
| ? | TR1376 | CAPSCREW - 1/2" - 13NC X 1 1/4" | 3 | ||||
| ? | C1540 | LOCKWASHER - 1/2" | 3 | ||||
| ? | VW6420 | CAP | 1 | ||||
| ? | TA9974 | FLANGE (W/ RECEIVER) | 1 | ||||
| ? | VH6864 | CAPSCREW - 1/4" - 20NC X 1/2" | 6 | ||||
| ? | DC3584 | LOCKWASHER - 1/4" | 6 | ||||
| ? | VW4748 | GASKET | 1 | ||||
| ? | TD0791 | CAPSCREW - 3/8" - 16NC X 1 1/4" | 6 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 6 | ||||
| ? | EK7337 | PLATE, ADAPTER | 1 | ||||
| ? | TA1691 | GASKET | 1 |
