| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58F-50-40100 | HOUSING | 1 | ||||
| ? | EH6541 | CAP, SUSPENSION | 1 | ||||
| ? | WA0363 | FLAT WASHER - 7/8" (HARDENED) | 60 | ||||
| ? | VN9161 | CAPSCREW - 7/8" - 9NC X 5" | 24 | ||||
| ? | WA1282 | RING, BACKUP (1) | 4 | ||||
| ? | WA5668 | SEAL, O-RING (1) | 4 | ||||
| ? | 58F-50-00210 | RETAINER, UPPER BEARING | 1 | ||||
| ? | PC2413 | BEARING, UPPER | 1 | ||||
| ? | EH6529 | STOP, PISTON | 1 | ||||
| ? | VW4451 | NUT | 1 | ||||
| ? | VC2629 | LOCKPIN (1) | 1 | ||||
| ? | H2981 | BALL, STEEL (1) | 4 | ||||
| ? | 58F-50-00200 | PISTON ASSEMBLY | 1 | ||||
| ? | 58F-50-00300 | • PISTON | 1 | ||||
| ? | 58B-50-00900 | • BOSS | 4 | ||||
| ? | EM3159 | • PLUG, PISTON | 1 | ||||
| ? | WA0443 | • SEAL, O-RING (1) | 1 | ||||
| ? | WA1443 | • RING, BACKUP (1) | 1 | ||||
| ? | EM1585 | • RING, RETAINER | 3 | ||||
| ? | EM1600 | • PLATE, RETAINER | 1 | ||||
| ? | WA0360 | • FLAT WASHER - 1/2" (HARDENED) | 1 | ||||
| ? | VN9032 | • CAPSCREW - 1/2" - 13NC X 1" | 1 | ||||
| ? | VM0314 | • PLUG (1) | 1 | ||||
| ? | EJ2182 | RETAINER, LOWER BEARING | 1 | ||||
| ? | PC2414 | BEARING, LOWER | 1 | ||||
| ? | VN9141 | CAPSCREW - 7/8" - 9NC X 4" | 24 | ||||
| ? | PB2194 | CHARGING VALVE ASSEMBLY (1)/(2) | 1 | ||||
| ? | TR9993 | • CAP, VALVE | 1 | ||||
| ? | TD7179 | • CORE, VALVE | 1 | ||||
| ? | TF1144 | • O-RING, HOUSING | 1 | ||||
| ? | WA0052 | • O-RING, VALVE STEM | 1 | ||||
| ? | VD5076 | GASKET, FLAT (1)/(2) | 1 | ||||
| ? | TY8879 | PLUG, VENT (1) | 1 | ||||
| ? | TZ8637 | PLUG | 1 | ||||
| ? | 58E-97-00051 | COVER, PROTECTOR | 1 | ||||
| ? | C1602 | CAPSCREW - 3/8" - 16NC X 1" | 2 | ||||
| ? | DF3042 | FLAT WASHER - 3/8" | 2 | ||||
| ? | PC0470 | SEAL, BUFFER (1) | 1 | ||||
| ? | PC0469 | SEAL, DOUBLE LIP (1) | 1 | ||||
| ? | PC0471 | SEAL, WIPER (1) | 1 | ||||
| ? | PLATE, DANGER | 2 | |||||
| ? | R1073 | DRIVE SCREW - #6 X .187 | 8 | ||||
| ? | EH6536 | KEY | 1 | ||||
| ? | VN9105 | CAPSCREW - 7/8" - 9NC X 3" | 12 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | AK4063 | SUSPENSION OIL MIXTURE (5 GAL) | 6 | ||||
| ? | AK4064 | SUSPENSION OIL MIXTURE (55 GAL) | 1 | ||||
| ? | 58F-FS-AK020 | NOTE: (1) INCLUDED IN 58F-FS-AK020 FRONT SUSPENSION | |||||
| ? | OVERHAUL KIT. | ||||||
| ? | RK1887 | (2) INCLUDED IN RK1887 CHARGING VALVE KIT. |
