| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | TY5960 | GUIDE, BODY | 2 | ||||
| ? | EF0742 | GUIDE, BODY | 1 | ||||
| ? | TY9407 | SHIM | 118 | ||||
| ? | EG8098 | PAD, BODY | 8 | ||||
| ? | TR6643 | NUT - 1/2" - 13NC | 32 | ||||
| ? | TR5445 | LOCKWASHER - 1/2" | 32 | ||||
| ? | WA4728 | FLAT WASHER - 1/2" (HARDENED) | 32 | ||||
| ? | C1619 | CAPSCREW - 1/2" - 13NC X 2 3/4" | 32 | ||||
| ? | BODY (1) | 1 | |||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | XC2293 | BLOCK, SPACER (2) | 2 | ||||
| ? | C1622 | CAPSCREW - 1/2" - 13NC X 3 1/2" (2) | 4 | ||||
| ? | NOTE: (1) ORDER FROM FACTORY. | ||||||
| ? | (2) USED FOR BODY PAD SHIMMING PROCEDURE ONLY. |
