| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | TANK, OIL RESERVE (1) | 1 | |||||
| ? | 58E-61-11031 | AUTOMATIC FILL CONTROL (AFC) BOX (1) | 1 | ||||
| ? | 58B-60-10010 | HOSE | 1 | ||||
| ? | 58F-60-40240 | HOSE | 1 | ||||
| ? | 08193-21012 | CLIP | 2 | ||||
| ? | 58B-06-20020 | BRACKET | 3 | ||||
| ? | 58F-06-10830 | SWITCH, THERMOSTAT | 1 | ||||
| ? | 58E-09-00000 | PLATE | 1 | ||||
| ? | C1531 | NUT - 1" 8NC | 4 | ||||
| ? | C1544 | LOCKWASHER - 1" | 4 | ||||
| ? | EK0195 | PLATE | 1 | ||||
| ? | EK9883 | SPACER | 1 | ||||
| ? | EM1393 | SPACER | 2 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 3 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 8 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 8 | ||||
| ? | MM0604 | CAPSCREW - M10 X 1.50 X 20 | 7 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 1 | ||||
| ? | MM0713 | FLAT WASHER - M10 (HARDENED) | 2 | ||||
| ? | SD5211 | BUSHING, PIPE | 1 | ||||
| ? | TD1549 | NUT - 1/4" - 20NC | 2 | ||||
| ? | TD1809 | CAPSCREW - 1/4" - 20NC X 3/4" | 2 | ||||
| ? | TR1307 | FLAT WASHER - 1/4" | 6 | ||||
| ? | WB0266 | FITTING, ELBOW - 90 DEG | 1 | ||||
| ? | WB0267 | FITTING, ELBOW - 90 DEG | 2 | ||||
| ? | WB0376 | FITTING, ELBOW - 90 DEG | 1 | ||||
| ? | WB1184 | NUT, COUPLING | 1 | ||||
| ? | WB3097 | CLAMP, CUSHIONED - 1/2" | 3 | ||||
| ? | WB3856 | CLAMP, CUSHIONED - 1 1/8" | 9 | ||||
| ? | WB3857 | CLAMP, CUSHIONED - 1 3/16" | 10 | ||||
| ? | 58E-61-00020 | TUBE, WITHDRAWAL (FLANGED) | 1 | ||||
| ? | 58F-60-10120 | GASKET | 1 | ||||
| ? | MM0606 | CAPSCREW - M10 X 1.50 X 30 | 2 | ||||
| ? | PC1262 | ADAPTER, STRAIGHT | 1 | ||||
| ? | WA4896 | FITTING | 1 | ||||
| ? | WB0467 | FITTING, STRAIGHT | 1 | ||||
| ? | 58E-61-00210 | NOTE: (1) INCLUDED IN 58E-61-00210 RESERVE SYSTEM KIT. |
