| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | 58F-40-00030 | TUBE, TIE ROD | 1 | ||||
| ? | 58F-40-00110 | END, ROD - RH | 1 | ||||
| ? | 58F-40-00100 | END, ROD - LH | 1 | ||||
| ? | C1613 | CAPSCREW - 1/2" - 13NC X 1 1/4" | 8 | ||||
| ? | C1540 | LOCKWASHER - 1/2" | 8 | ||||
| ? | EK1030 | RETAINER, ANTI-ROTATION (1) | 2 | ||||
| ? | PC1686 | BEARING, SPHERICAL (1) | 2 | ||||
| ? | VN9202 | CAPSCREW - 1" - 8NC X 7" | 8 | ||||
| ? | WA0364 | FLAT WASHER, HARDENED - 1" | 16 | ||||
| ? | VH8186 | LOCKNUT - 1" - 8NC | 8 | ||||
| ? | 58F-40-00050 | CLAMP, ROD END | 4 | ||||
| ? | AK4323 | NOTE: (1) INCLUDED IN AK4323 STEERING CYLINDER AND | |||||
| ? | TIE ROD PIN KIT. |
