| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE4064 | SEAL, DUST (1) | 1 | ||||
| ? | VE3080 | HOUSING/SPOOL/SLEEVE | 1 | ||||
| ? | VE3081 | BALL | 1 | ||||
| ? | VE3082 | BUSHING, THREADED | 1 | ||||
| ? | BF3031 | O-RING (1) | 2 | ||||
| ? | VE3083 | BEARING ASSEMBLY | 1 | ||||
| ? | VE3084 | RING | 1 | ||||
| ? | VE3085 | CROSS PIN | 1 | ||||
| ? | BF3032 | SPRING SET (QTY. 6) | 1 | ||||
| ? | BF1287 | SHAFT, CARDAN | 1 | ||||
| ? | VE4069 | O-RING (1) | 1 | ||||
| ? | BF3033 | PLATE, INTERMEDIATE | 1 | ||||
| ? | VE4071 | O-RING (1) | 3 | ||||
| ? | BF3034 | PLATE, DISTRIBUTOR | 1 | ||||
| ? | BF3035 | GEAR WHEEL SET | 1 | ||||
| ? | VE3091 | COVER, END | 1 | ||||
| ? | VE4072 | WASHER (1) | 7 | ||||
| ? | BF3036 | CAPSCREW W/ PIN (SPECIAL) | 1 | ||||
| ? | BF3037 | CAPSCREW | 6 | ||||
| ? | NAME PLATE (2) | 1 | |||||
| ? | DRIVE SCREW (2) | 1 | |||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | BF3038 | NOTE: (1) INCLUDED IN BF3038 SEAL KIT. | |||||
| ? | (2) NOT SERVICED SEPARATELY. |
