Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
AK5188 |
STANDARD RIM ASSEMBLY (INNER) (SEE FIG 56033) |
2 |
|
56033 |
|
|
? |
EJ2283 |
PLATE, BENT |
1 |
|
|
|
|
? |
C1547 |
FLAT WASHER - 3/8" |
2 |
|
|
|
|
? |
C1601 |
CAPSCREW - 3/8" - 16NC X 3/4" |
2 |
|
|
|
|
? |
C0312 |
LOCKWASHER - 3/8" |
2 |
|
|
|
|
? |
EJ5600 |
ADAPTER, RING ASSEMBLY (OUTER) |
1 |
|
|
|
|
? |
EJ5599 |
• RING, ADAPTER |
1 |
|
|
|
|
? |
EH0826 |
• STUD W/ HEAD |
57 |
|
|
|
|
? |
WB1134 |
NUT - 1 1/4" - 7NC |
168 |
|
|
|
|
? |
EM5451 |
STUD, WHEEL |
54 |
|
|
|
|
? |
PC0579 |
CONNECTOR, SWIVEL NUT |
2 |
|
|
|
|
? |
PC0580 |
SPUD, COLLIE |
2 |
|
|
|
|
? |
PC0581 |
EXTENSION, FLEXIBLE |
2 |
|
|
|
|
? |
PC0583 |
HOUSING, CORE |
3 |
|
|
|
|
? |
PC1480 |
EXTENSION, BENT |
1 |
|
|
|
|
? |
WA4706 |
CLAMP, HYDRA ZORB - 3/4" |
2 |
|
|
|
|
? |
PC0663 |
EXTENSION, FLEXIBLE (OUTER) |
1 |
|
|
|
|
? |
EH5760 |
PLATE, BENT |
1 |
|
|
|
|
? |
|
(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
|
|
|
|
